High Reliability and Flexibility

TECHNICAL DATA

MAIN FEATURES

Drive system

2 AC drive motors each 80V, 29 kW
Single gear PMS

Battery

850 Ah lead-acid batteries

Battery charger

80V HF charger, with charge level indicator, approx. 6 hours charging time, external

Brake

Hydraulic oil-multi-disc brake, low-wear in the drive gear,
parking brake disc brake

Speed

Forward and backward:
max. about 25 km/h

Frame

Loading weight: 11200 kg,
for aeroplanes approx. 100.0 t MTOW
weight empty: 8430 kg

Steering

AC-Contoller 72-96 V 650A
electro-hydraulic steering operated by steering wheel

Landing gear bracket

Universal receptacle for double front landing gear, up to width tire 1150 mm, with hydraulic front gear wheel hold system, hydraulic door closing system

Tire

Drive wheels: 23 x 9-10 Solid Tire
Steering wheel: 16 x 6-8 Solid Tire

Lighting / Safety

  • emergency stop
  • LED light package after StVZO
  • Safety up turn light on top
  • Windshield wipers in the front and rear with wash
  • heating
  • signal horn
  • fire-extinguisher

Adapted for

Airbus, Boeing, Beechcraft, Cessna, Challenger, Embraer, Falcon, Gulfstream, Hawker
